Introduction

Echocardiography (TTE/TEE) in anesthesia is not about a full cardiology report. Instead, it is about identifying parameters that affect anesthetic safety: myocardial contractility, filling pressures, valve function, chamber sizes, pulmonary pressures, pericardial constraints, and aortic pathology.

🗣️ Listen now on - Apple, Spotify & all other major podcast platforms.

Each parameter below is explained with:

  • What it measures

  • Normal value

  • Abnormal cut-offs

  • Clinical anesthesia relevance


Step 1. Left Ventricular (LV) Systolic Function

Ejection Fraction (EF)

  • What it is: Percentage of blood ejected from LV per beat, marker of global systolic function.

  • Normal: 55–70%

  • Abnormal: <40% = systolic dysfunction; <30% = severe risk

  • Anesthesia relevance: Low EF patients cannot tolerate myocardial depressants (propofol, volatiles). Etomidate is favored. They need gentle induction, careful fluids, and early vasopressor/inotrope use.

Reference: Lang RM, et al. Eur Heart J Cardiovasc Imaging. 2015;16(3):233-70.


Step 2. LV Diastolic Function

E/A Ratio (Mitral inflow velocities)

  • What it is: Ratio of early (E) to late atrial (A) ventricular filling. Reflects LV compliance.

  • Normal: 1.0–1.5

  • Abnormal: <0.8 = impaired relaxation (Grade I); >2 = restrictive filling (Grade III)

  • Relevance: Diastolic dysfunction makes patients preload- and rhythm-dependent. Tachycardia reduces filling, leading to hypotension and ischemia.

E/e′ Ratio (LV filling pressure)

  • What it is: Ratio of mitral inflow (E) to mitral annular tissue Doppler (e′). Estimates LV filling pressure.

  • Normal: <8

  • Abnormal: >15 = high filling pressures

  • Relevance: High filling pressures mean risk of pulmonary edema perioperatively; avoid fluid overload.

LA Volume Index

  • What it is: Surrogate of chronic diastolic dysfunction.

  • Normal: 16–34 mL/m²

  • Abnormal: >40 mL/m² → diastolic dysfunction, AF risk

  • Relevance: Enlarged LA predicts atrial fibrillation during or after surgery.

Reference: Nagueh SF, et al. Eur Heart J Cardiovasc Imaging. 2016;17(12):1321-60.


Step 3. Right Ventricular (RV) Function

TAPSE (Tricuspid Annular Plane Systolic Excursion)

  • What it is: RV longitudinal contraction measured at the tricuspid annulus.

  • Normal: ≥17 mm

  • Abnormal: <17 mm = RV dysfunction

  • Relevance: Low TAPSE indicates poor RV reserve → patients cannot tolerate ↑PVR (hypoxia, hypercarbia, high PEEP).

RV FAC (Fractional Area Change)

  • What it is: Ratio of RV systolic to diastolic area change.

  • Normal: >35%

  • Abnormal: <35% = RV systolic dysfunction

  • Relevance: Helps predict RV failure intraoperatively.

RV S′ (Tissue Doppler velocity)

  • What it is: Longitudinal systolic velocity at tricuspid annulus.

  • Normal: ≥10 cm/s

  • Abnormal: <10 cm/s = RV dysfunction

  • Relevance: Confirms poor RV contractility; these patients need inotropes (dobutamine, milrinone).

RA Size

  • Normal: <18 cm²

  • Abnormal: >18 cm² = RA enlargement, often due to PH or severe TR

  • Relevance: Suggests chronic venous congestion → perioperative fluid management must be cautious.

Reference: Rudski LG, et al. J Am Soc Echocardiogr. 2010;23(7):685-713.


Step 4. Valves

Aortic Valve

Aortic Valve Area (AVA)

  • Normal: 3–4 cm²

  • Severe AS: <1 cm²

  • Mean Gradient: Severe if >40 mmHg

  • Relevance: Severe AS = fixed cardiac output. Avoid hypotension, tachycardia, vasodilation. Use phenylephrine, maintain sinus rhythm.

Reference: Otto CM, et al. J Am Coll Cardiol. 2021;77(4):e25-197.


Mitral Valve

Mitral Valve Area (MVA)

  • Normal: 4–6 cm²

  • Severe MS: <1.5 cm²

  • Relevance: MS patients need slow HR, preserved preload, and prevention of ↑PVR (avoid hypoxia, hypercarbia).

Mitral Regurgitation (MR severity)

  • Normal: None or trace

  • Severe: Regurgitant volume >60 mL, vena contracta >0.7 cm

  • Relevance: Severe MR worsens with ↑afterload; anesthesia should aim for ↓afterload, slightly faster HR.

Reference: Zoghbi WA, et al. J Am Soc Echocardiogr. 2017;30(4):303-71.


Tricuspid Valve

Tricuspid Regurgitation (TR severity)

  • Normal: Mild TR is physiologic

  • Severe TR: Jet area >10 cm², vena contracta >0.7 cm

  • Relevance: Severe TR causes venous congestion, liver dysfunction, and RV dilation. Fluids must be cautious; RV support is key.

Reference: Rudski LG, et al. J Am Soc Echocardiogr. 2010;23(7):685-713.


Step 5. Chambers & Pulmonary Pressures

LA Volume Index

  • Normal: 16–34 mL/m²

  • Abnormal: >40 mL/m² → chronic diastolic dysfunction

  • Relevance: Predicts AF, perioperative hemodynamic instability.

PASP (Pulmonary Artery Systolic Pressure)

  • Normal: <35 mmHg

  • Abnormal:

    • Mild PH: 36–45 mmHg

    • Moderate PH: 46–60 mmHg

    • Severe PH: >60 mmHg

  • Relevance: Severe PH patients cannot tolerate ↑PVR; periop mortality is high. Avoid N₂O, hypercarbia, acidosis. Consider inhaled NO or milrinone.

Reference: Galiè N, et al. Eur Heart J. 2016;37(1):67-119.


Step 6. Pericardium & Aorta

Pericardial Effusion

  • Normal: <10 mm

  • Large: >20 mm

  • Relevance: Large effusion with tamponade physiology = preload dependent. Avoid PPV until drainage; induction with ketamine/etomidate is preferred.

Aortic Root Diameter

  • Normal: <40 mm (men), <38 mm (women)

  • Abnormal: >45 mm = aneurysm risk

  • Relevance: Aneurysmal aorta is prone to rupture with hypertension or sympathetic surges. Avoid high BP; maintain β-blockade.

References:

  • Adler Y, et al. Eur Heart J. 2015;36(42):2921-64.

  • Erbel R, et al. Eur Heart J. 2014;35(41):2873-926.


Dominant Lesion Principle

When multiple findings coexist, the lesion with the highest mortality risk dominates management:

  • Severe AS > MR

  • Severe PH > mild RV dysfunction

  • Tamponade > Low EF

Reference: Kristensen SD, et al. Eur Heart J. 2024;45(29):2501-96.


Case-Based Scenarios

Case 1: EF 25%, laparotomy

  • EF <30% (severe dysfunction).

  • Induction: Etomidate + opioids.

  • Maintenance: Low-dose volatile, NE infusion.

  • Pitfall: Propofol bolus → collapse.

Case 2: Severe AS, hip fracture

  • AVA <1 cm².

  • Strategy: Slow induction, avoid spinal, phenylephrine.

  • Pitfall: Tachycardia → ischemia.

Case 3: Severe PH, laparoscopy

  • PASP >60 mmHg.

  • Strategy: Avoid N₂O, high PEEP, use NO/milrinone.

  • Pitfall: Hypercarbia → RV failure.

Case 4: Tamponade for pericardial window

  • Large effusion with RA collapse.

  • Strategy: Ketamine induction, maintain SV.

  • Pitfall: PPV before drainage → CV collapse.

Reference: Mahmood F, et al. Anesth Analg. 2016;122(6):1784-96.


Conclusion

Every echocardiographic parameter relevant to anesthesia has a normal range, a dangerous cut-off, and a direct anesthetic implication. By knowing what each parameter measures, and what abnormality means intraoperatively, anesthesiologists can tailor anesthetic techniques, monitoring, and drug strategies to optimize patient safety.
